1-5948-01-28 Rotary Shaking Bath with Pre-shipment Validation SBR-20
Product Description
Product Model: 1-5948-01-28Product Brand: AS ONE Corpor […]
Contact Us
Product Details
Product Model: 1-5948-01-28
Product Brand: AS ONE Corporation
Features
- It is a shaking water tank with high agitation efficiency and a swirl shaking system.
- The water tank is detachable, so it is easy to change the water.
- If the thermal robot series is set, it can be ***d as a constant temperature swirl shaking water tank.
- The shaking rack for holding test tubes, flasks, etc. is a double spring system.
Spec
- Validated products are Azuwan original services that conduct FAT (Factory Acceptance Test) at Azuwan before shipping.
- Validate (FAT) before shipping.
- After receiving the order, a FAT instruction form (plan) is sent to the ***r, and after the signature is returned, the FAT is performed.
- App***ix: FAT report/Calibration Certificate of ***d measuring instrument copied
- *I am attaching Azwan's original FAT instruction manual (see the sample at the bottom left of the Screen).
- Temperature point: number of revolutions
- Shaking speed: 20 mm (turning)/20 ~ 160 rpm
- Number of shaker racks: 252 test tubes of 10 mm diameter
- Water tank material: stainless steel (SUS 304)
- Tank capacity: 20 L
- Swirl shaking system
- Shaking table dimensions: 244 x 290 x 130 mm
- External dimensions (mm): 495 x 570 x 275
- Tank internal dimensions (mm): 300 x 500 x 150
- Power: 100 VAC, 50/60 Hz, 100 W
- Power cord length: 2.5 m, 3 P plug with ground pin
- Accessories: Shaking rack (SUS 304)
- Local validation services (IQ/OQ) are also available. Please contact us.
- *The on-site validation service is a service that performs installation qualification (IQ) and operational performance qualification (OQ) at the installation site and submits an inspection form.
- *If you would like to request a local IQOQ, please contact us separately. We need your installation address for the estimate.
