Spec

• Validated products are Azuwan original services that conduct FAT (Factory Acceptance Test) at Azuwan before shipping.
• Validate (FAT) before shipping.
• After receiving the order, a FAT instruction form (plan) is sent to the ***r, and after the signature is returned, the FAT is performed.
• App***ix: FAT report/Calibration Certificate of ***d measuring instrument copied
• *I am attaching Azwan's original FAT instruction manual (see the sample at the bottom left of the Screen).
• Temperature point: 1 point of 800 degrees Celsius
• External dimensions: 210 x 260 x 290 mm
• Inner furnace dimensions (mm): 90 x 110 x 70 (* Including sensor protrusions)
• Storage capacity (L): 0.7
• Temperature setting range: 100 ~ 900 degrees C
• Temperature control method: PID control
• Sensor: K-type thermocouple
• Timer: ON/OFF/SV Timer
• Time setting range: 0 minutes to 99 hours 59 minutes
• Temperature setting resolution: 1 °C
• Timing resolution: 1 minute
• Safety mechanism: Sensor fault detection, excessive rise prevention relay, overcurrent f***
• Material: Exterior/Steel Heat resistant coating, Furnace/Ceramic fiber
• Power: 100 VAC, 50/60 Hz
• Power cord length: 2 m (2P plug)
• Weight: approximately 5 kg
• Heater: 500 W
• Program functions: None
• This product can be inspected and inspected.　Please contact us.
• *Inspection Certificate service is a service that carries out inspections of the control relation (measured temperature inside the wareho***, etc.) and the power engine personnel at the time of shipment or at the customer's site, and issues inspection documents.
• *If you would like to request a local IQOQ, please contact us separately. We need your installation address for the estimate.
