Spec

• External Dimensions (WDH) (mm): 210 x 260 x 290
• Furnace Inner Dimensions (mm): 90 x 110 x 70 (* Including Sensor Protrusion)
• Internal Capacity (L): 0.7
• Temperature Setting Range: 100~900°C
• Temperature control system: PID control
• Sensor: K-Type Thermocouple
• Timer: ON/OFF/SV Timer
• Time Setting Range: 0 Minute - 99 hours 59 minutes
• Temperature setting resolution: 1°C
• Time setting resolution: 1 minute
• Safety Mechanism: Sensor Abnormality Detection, Excess Temperature Rise Prevention Relay, Overcurrent F***
• Material: Exterior/Steel Heat-Resistant Coating, Furnace/Ceramic Fiber
• Power: 100 VAC, 50/60Hz
• Power Cord Length: 2 m (2P Plug)
• Weight: approx. 5 kg
• Heater: 500 W
• Program function: None
• This product can provide inspection and inspection services. Please contact us.
• *The inspection and inspection service is a service that inspects the control system (internal temperature measurement, etc.) and the electric locomotive at the time of shipment or at the customer's site, and issues inspection reports.
