63-4972-60 Harting 6 Way Unscreened Flat Ribbon Cable, 7.28 mm Width, 30m 9180067001
Electronic/Electrical Parts and Controll Equipments

63-4972-60 Harting 6 Way Unscreened Flat Ribbon Cable, 7.28 mm Width, 30m 9180067001

model: 63-4972-60
brand: HARTING

Product Description

Product Model: 63-4972-60Product Brand: HARTING Feature […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-4972-60
Product Brand: HARTING

Features

  • UL, CSA. Flat cable 1.27 mm. A flat cable from Harting for insulation displacement termination. Features and Benefits · Edge mark on first conductor · UL AWM-style 2651 CSA · PVC insulation, grey · Copper tinned

Spec

  • Quantity:1roll(30m)
  • Number of Ways : 6
  • Pitch : 1.27mm
  • American Wire Gauge : 28
  • Reel Length : 30m
  • Width : 7.28 mm
  • Cable Shape : Ribbon
  • Sheath Colour : Grey
  • Voltage Rating : 300 V
  • Screened/Unscreened : Unscreened
  • Conductor Strand Type : Stranded
  • Number of Strands : 7
  • Minimum Operating Temperature : -20°C
  • Maximum Operating Temperature : +105°C
  • Characteristic Impedance : 105 Ω
  • CODE No.:693-7699
