Spec

• Cut length: 10m
• Format: ORP-D 1.25SQX2C(SB)(2586)
• Conductor section size: 1.25sq
• UL SYLE： No. 2586 (rated 105°C 600V)
• Conductor: Tin plating annealed copper stranded wire
• Insulant: Special elastomer
• Sheath material: Oilproof PVC (black matting)
•

• Number of sliding bent times: 100 million times or more
• Bent radius R: About 6 times as big as cable outer diameter
• Sliding speed: 70 times/min
• Moving distance: 350mm
• Number of swinging bent times: 20 million times or more
• Bent radius R: About 8 times as big as cable outer diameter
• Bent angle: ±90°
• Bent speed: 40 times/min
• Load: 4.9N
• Count: Counting 1 round trip as 1 time
• Number of twisting bent times: 20 million times or more
• Twisting angle: ±180°
• Twisting speed: 70 times/min
• Spacing X: 500mm
