61-6997-03 Fixed Type Lens Holder Compatible Optics Size Φa: Φ10mm Effective Diameter Φb: Φ7mm LHF-10S
Product Description
Product Model: 61-6997-03Product Brand: SIGMAKOKI CO., […]
Contact Us
Product Details
Product Model: 61-6997-03
Product Brand: SIGMAKOKI CO., LTD.
Features
- Slimmer outer diameter than previous lens holders.
- You can fix thin lenses to thick lenses such as Achromart.
- Ideal for optical systems where the holders are close together or where the folded beam passes right next to the lens holder.
- If you remove the rod and replace it with a post stand (PST -**), you can set the optical axis height from the base to a comfortable height such as 55 mm or 60 mm.
- The mounting side of the inch screw allows you to set the height to the inch size (However, the post stand is not the height of the inch size.).
- The plastic (Delrin) screw ring allows the lens to be securely fastened without damaging the lens.
- Holders (LHF) for lenses larger than φ80 mm are also available.
- * Resin powder may be generated when the resin screw ring rubs against the body.
- * When using in a clean room or using a high power laser, replace with an aluminum screw ring (RR -**).
Spec
-
[
common specification]
- Major material: Aluminum
- Surface treatment: Black anodic oxide
- [Individual specification]
- Compatible optics size φA: φ10mm
- Effective diameter φB: φ7mm
- C: M10.85 P0.75
- D: 15mm
- E: 4mm
- F: 12mm
- φG: φ17mm
- H: 34.05mm
- I: ?
- Compatible optics thickness: 2 - 7mm
- Mass: 0.06kg
- RoHS conform product
