61-6989-25 Kinematic Type Small Mirror Holder MMH-50H
Analyzer, Testing Equipment

61-6989-25 Kinematic Type Small Mirror Holder MMH-50H

model: 61-6989-25
brand: SIGMAKOKI CO., LTD.

Product Description

Product Model: 61-6989-25Product Brand: SIGMAKOKI CO., […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 61-6989-25
Product Brand: SIGMAKOKI CO., LTD.

Features

  • Kinematic mirror holder that can easily fix the mirror.
  • □ Various sizes of mirrors under 50 mm can be glued together for ***.
  • The mirror of φ40 mm can be fixed using the mirror presser screw.
  • By removing the top mounting bracket and pins, the □ 50 mm mirror can be glued and fixed.
  • □ 50 mm square aluminum flat mirror (TFA-50S08-10) is available.
  • * Since this is a kinematic mirror holder, the center of rotation of the fine adjustment mechanism is not located on the reflecting surface of the mirror.
  • * A gimbal mirror holder (MHAN) with the center of rotation of fine adjustment located on the reflecting surface of the mirror is also available.

Spec

  • [

    common specification]
  • Major material: Aluminum
  • Surface treatment: Black anodic oxide
  • [Individual specification]
  • Compatible optics size: <□50mm/φ40mm
  • Small adjustment range (tilt): ±4°
  • Small adjustment range (rotation): ±4°
  • Resolution (tilt): Approximately 0.38°/rotation
  • Resolution (rotation): Approximately 0.38°/rotation
  • Mass: 0.2kg
  • RoHS conform product
