Features

• Base plate for fixing φ20 mm post stand. It is ***d when thin elements such as lenses and polarizers are placed close to each other on the optical axis. Up to 3 φ20 mm post stands can be placed at intervals of 64 mm.
• Beca*** the base plate has a bottom, the optical axis height is raised by 5 mm.
• Since the width is 2 mm shorter than the post stand, the base plate does not interfere with the proximity of the elements.
• The post stand is fixed from the side with 1~2 set bolts.
• Set bolts are attached in 4 directions so you can access from any direction.
