61-6984-82 SFS Controller CJ-200A
Analyzer, Testing Equipment

61-6984-82 SFS Controller CJ-200A

model: 61-6984-82
brand: SIGMAKOKI CO., LTD.

Product Description

Product Model: 61-6984-82Product Brand: SIGMAKOKI CO., […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 61-6984-82
Product Brand: SIGMAKOKI CO., LTD.

Spec

  • [

    Common specification]
  • Major function controller function: ○
  • Major function number of control axes: FINE-01γ (**) 1 axis, FINE-503 (**) 3 axes
  • Major function internal program control: ○
  • Major function feedback control: Digital sensor
  • General specification power voltage: The *** of product number: (CL) AC 100V ±10% (UL) AC 120V ±10% (CE) AC 230V ±10% 50/60 Hz
  • General specification power consumption: 50VA
  • General specification operation temperature: 10 - 30℃
  • General specification storage temperature: -20 - 60℃
  • General specification ambient humidity: 20 - 80%RH
  • General specification outer dimensions (W x H x D): FINE-01γ (**) 225 x 118 x 250mm, FINE-503(**) 270 x 118 x 297mm
  • General specification weight: FINE-01γ(**) 3.5kg, FINE-503(**) 5.3kg
  • Interface GP-IB: FINE-01γ(**) -, FINE-503(**) ○
  • Interface RS232C: ○
  • Interface USB: ○
  • Interfaces analog input: FINE-01γ(**) ○, FINE-503(**) -
  • Performance specification coordinate display range: ±999,999nm
  • Performance specification maximum setting movement amount: ±999,999nm
  • Control command return to mechanical origin: ○
  • Control command logical origin setting: ○
  • Control command relative position drive: ○
  • Control command absolute position drive: ○
  • Control command jog operation: ○
  • Control command position specifications: -
  • Control command circular interpolation control: -
  • Control command straight line interpolation control: -
  • Control command drive: ○
  • Control command decelerating stop: -
  • Control command emergency stop: -
  • Control command speed settings: ○
  • Control command motor free/hold: -
  • Control command port input: -
  • Control command port output: -
  • [Individual specification]
  • Product name: Control pad:
