61-6981-90 Micrometer Head (Maintenance Parts) Movement Amount 15mm Or Less 0 - 6mm 0.06kg SFN-01
Analyzer, Testing Equipment

61-6981-90 Micrometer Head (Maintenance Parts) Movement Amount 15mm Or Less 0 - 6mm 0.06kg SFN-01

model: 61-6981-90
brand: SIGMAKOKI CO., LTD.

Product Description

Product Model: 61-6981-90Product Brand: SIGMAKOKI CO., […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 61-6981-90
Product Brand: SIGMAKOKI CO., LTD.

Features

  • This is a micrometer head with a displacement of 15 mm or less that is ***d for manual stages and holders of the company.
  • Please **** that we do not issue proofs.
  • * When replacing the micrometer head, the movement range may be narrowed or interference with the mounting components may occur dep***ing on the type of stage.
  • * When replacing the micrometer head, we recomm*** that you check with the company.

Spec

  • Movement amount: 0 - 6mm
  • Type: Fine pitch
  • Minimum reading: 0.005mm
  • Movement amount/1 rotation: 0.25mm
  • Allowable load (static load): 19.6N (2kgf)
  • Mass: 0.06kg
  • RoHS conform product
