61-6980-46 Direct-Acting Stainless Steel Way (Impulse Way) 15 x 15mm IPWS-F1515
Analyzer, Testing Equipment

61-6980-46 Direct-Acting Stainless Steel Way (Impulse Way) 15 x 15mm IPWS-F1515

model: 61-6980-46
brand: SIGMAKOKI CO., LTD.

Product Description

Product Model: 61-6980-46Product Brand: SIGMAKOKI CO., […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 61-6980-46
Product Brand: SIGMAKOKI CO., LTD.

Features

  • It is a high-precision linear moving guide of an integrated type with a two-plate configuration, in which the guide is processed, quenched and ground directly on the lower plate and the moving table (upper plate), and steel balls are arranged.
  • Pressurization: There are two types of pressurization for a direct motion guide. ① Standard pressurization provides zero or slight pressurization, resulting in smooth movement. ② Since light pressurization provides a higher pressurization than standard pressurization, it is suitable for environments that increase rigidity and receive light vibration.

Spec

  • [

    Common specification]
  • Movement guide: Ball guide
  • Main material: Stainless Seel (SUS440C) equivalent
  • Surface treatment: No
  • [Individual specification]
  • Table surface size: 15 x 15mm
  • Movement amount: ±3mm
  • Parallelism: 30μm
  • Movement parallelism: 10μm
  • Maximum moment Fx': 0.4N・m
  • Maximum moment Fy': 0.8N・m
  • Permissible moment Fθ': 0.4N・m
  • Mass: 0.01kg
  • RoHS conform product
