61-6980-29 Θαβ Axis Small Thin Stage Φ25mm KKD-25c KKD-25C
Analyzer, Testing Equipment

61-6980-29 Θαβ Axis Small Thin Stage Φ25mm KKD-25c KKD-25C

model: 61-6980-29
brand: SIGMAKOKI CO., LTD.

Product Description

Product Model: 61-6980-29Product Brand: SIGMAKOKI CO., […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 61-6980-29
Product Brand: SIGMAKOKI CO., LTD.

Features

  • A tilting/rotating stage for tilting and tailgating a specimen on a table surface to any angle.
  • Its small size and thin profile make it ***ful for constrained spaces and small optical systems.
  • The adjustment ring can be tilted and the feed knob can be rotated.
  • Since it is for light load, please be careful about the load.

Spec

  • Table surface size: φ25mm
  • Rotation range: ±3°
  • Slope range/α axis: ±3°
  • Slope range/β axis: ±3°
  • Movement amount by 1 rotation of the knob/θ axis: Approximately 0.9°
  • Movement amount by 1 rotation of the knob/α axis: Approximately 2.2°
  • Movement amount by 1 rotation of the knob/β axis: Approximately 2.2°
  • Main material: Aluminum
  • Surface treatment: Black anodic oxide
  • Withstand load: 1.0N (0.1kgf)
  • Mass: 0.05kg
  • RoHS conform product
