61-6974-65 Z Axis Large Type Stage TSM-2003
Product Description
Product Model: 61-6974-65Product Brand: SIGMAKOKI CO., […]
Contact Us
Product Details
Product Model: 61-6974-65
Product Brand: SIGMAKOKI CO., LTD.
Features
- A large stage with a thin stage surface using a jack screw system.
- Turn the side handles to move the top of the stage up or down.
- The handles are interlocked, so operating one of them will move the stage plane.
- The transparent hole in the center of the stage always maintains the through hole diameter even if the table is moved.
Spec
-
[
common specification]
- Movement guide: Jack screw method
- Main material: Aluminum
- Surface treatment: Black anodic oxide
- Movement amount/1 rotation: 1mm
- Movement accuracy/straightness: 200μm
- Display resolution: 1mm
- RoHS conform product
