Product Details

Product Model: 61-6960-34
Product Brand: SIGMAKOKI CO., LTD.

Features

  • This is the highest performance vibration isolator with high vibration isolation effect in both vertical and horizontal directions, beca*** horizontal vibration isolation is carried out by the three-dimensional vibration isolation method using the "universal mechanism (applying the p***ulum principle)" and vertical vibration isolation is carried out by the "precision air spring."
  • It is a vibration isolator that quickly attenuates vibration that is transmitted to the equipment and devices to be installed. It is indispensable as a mounting platform for equipment and devices that do not like the effect of vibration.
  • The bench has a honeycomb core shape and is made of aluminum, so it is lightweight and has excellent rigidity.
  • The upper surface of the bench is a magnetized stainless steel plate with tap holes (M6 25 x 25 mm matrix) on the entire surface, so it can be built with either magnet type or screw-on type equipment or equipment.
  • Manual models are only available in sizes that allow workers to supply air using a hand air pump without strain.
  • A quiet type silent compressor (PC-10H-S) that can be ***d indoors is available when the compressor is installed in a place where there is no air source.
  • The watch may not function properly if it is loaded with an extremely biased load or equipment or equipment with an abnormally high center of gravity.

Spec

  • [

    common specification]
  • Natural frequency (vertical direction): Approximately 1.3Hz
  • Natural frequency (horizontal direction): Approximately 0.5Hz
  • Vibration prevention (vertical direction): Precision air spring
  • Vibration prevention (horizontal direction): Universal mechanism
  • Control method (vertical direction): Air damping by orifice
  • Control method (horizontal direction): Damping with special rubber
  • Honeycomb material inner bench: Aluminum
  • Bench material (top plate): Magnetic Stainless Steel plate, thickness 5mm
  • Bench material (side): Black vinyl leatherette bonded to plywood
  • Bench material (lower panel): Regular steel plate (hot rolled steel plate), thickness 4.5mm
  • Bench top: M6 tapped holes on 25 x 25mm matrix over the entire surface (leaving 25mm around the edges)
  • Bench top surface finish: Unpainted (satin finish)
  • Features: The manual leveling system is best suited for mounting instruments that do not change position or weight. The height of the bench is easily adjusted by operating the supply and exhaust valve. Air supply is provided with the accessory hand air pump, and no other air source is required.
  • Air supply: Manually supplied with the hand air pump
  • Air supply air pressure: ―
  • Horizontal maintenance: Manual adjustment by means of three supply and exhaust valves
  • Accessories: One hand air pump, One special rotation driver for supply and exhaust valve
  • *1MPa ? 10.197 kgf/cm2
  • [Individual specification]
  • Type: Automatic vertical leveling
  • A x B: 1,200 x 900mm
  • H: 750mm
  • T: 100mm
  • Weight installable weight: 1,961N (about 200 kgf)
  • Mass: 192kg
  • RoHS conform product
