61-6914-34 Cylindrical Plano-Convex Lens BK 10 x 10mm Focal Length 15mm CLB-1010-15P
Product Description
Product Model: 61-6914-34Product Brand: SIGMAKOKI CO., […]
Contact Us
Product Details
Product Model: 61-6914-34
Product Brand: SIGMAKOKI CO., LTD.
Features
- Cylindrical plano-convex lenses (cylindrical plano-convex lenses) have the curvature of a convex lens in the vertical direction and no curvature in the horizontal direction.
- It is ***d to produce a wide sheet of light ***d in experiments where laser light is condensed into thin lines and fluid measurements.
- A lens made by BK7 for the visible to near-infrared range.
- Three types of lenses with anti-reflection films are also available in the visible, near-infrared and infrared ranges.
- By using a cylindrical lens in the optical system, the beam shape and the aspect ratio of the illumination light can be deformed.
- A cylindrical lens holder (CHA) is available for fixing cylindrical lenses.
- * Cylindrical plano-convex lenses have chromatic aberration, and the focal length dep***s on the wavelength.
- Cylindrical plano-convex lenses allow light to enter in certain directions.
- * Be sure to allow parallel light to enter from the convex side.
- Doing so can ca*** spherical aberration to increase, which in turn can ca*** condensation lines to become thicker.
- * The transmittance of the uncoated product is about 90% due to the loss ca***d by the reflection of the front and back of the lens.
Spec
-
[
common specification]
- Material: BK7
- Design wavelength: 546.1nm
- Refractive index: n e=1.519
- Coating: No coat
- Effective diameter: Circle or ellipse inscribed to 90% of rectangle against outer dimensions
- Scratch - dig: 20-10
- [Individual specification]
- Reflective prevention film coat wavelength region: No coat
- A x B: 10 x 10mm
- Focus distance f: 15mm
- Edge thickness te: 2.2mm
- Center thickness tc: 4mm
- Back focus fb: 12.4mm
- Curvature half diameter r: 7.79mm
- RoHS conform product
