61-6884-36 Mica Waveplate φ10mm WPM-10-2P
Analyzer, Testing Equipment

61-6884-36 Mica Waveplate φ10mm WPM-10-2P

model: 61-6884-36
brand: SIGMAKOKI CO., LTD.

Product Description

Product Model: 61-6884-36Product Brand: SIGMAKOKI CO., […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 61-6884-36
Product Brand: SIGMAKOKI CO., LTD.

Features

  • Wavelengths ***d for simple experiments and observation systems.
  • Mica crystals are thinly sliced and sandwiched with glass plates.
  • There are two types of wave plates: a 1/2 wave plate that can rotate the polarization direction and a 1/4 wave plate that can convert linearly polarized light into circularly polarized light.
  • Since the element is sandwiched by two pieces of glass, handling is easy.
  • A crystal wave plate (WPQ) with high accuracy of phase difference is also available. *Do not *** near high-power lasers or high temperature light sources.
  • * The phase difference dep***s on the wavelength. *Please make sure that there are no problems before purchasing.
  • * Since natural mica is ***d, the rating may vary dep***ing on the product.
  • * Use a crystal wave plate for polarimetry.

Spec

  • [

    common specification]
  • Material: Mica of sheet, Glass plate (2 sheets)
  • Adaptive wavelength: 400 - 700nm
  • Transmitted wavefront accuracy: 2λ λ=550nm
  • Incident angle: 0°
  • Design wavelength: 580nm
  • Retardation in the design: 1/4 wavelength plate 145nm, 1/2 wavelength plate 290nm
  • Scratch - dig: 40-20
  • [Individual specification]
  • Type: λ/2
  • Outer diameter φD: φ10mm
  • Thickness t: 2.5mm
  • RoHS conform product
