61-6882-29 Color Correction Filter Average Transmittance 84.2% CCF-50S-500C
Analyzer, Testing Equipment

61-6882-29 Color Correction Filter Average Transmittance 84.2% CCF-50S-500C

model: 61-6882-29
brand: SIGMAKOKI CO., LTD.

Product Description

Product Model: 61-6882-29Product Brand: SIGMAKOKI CO., […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 61-6882-29
Product Brand: SIGMAKOKI CO., LTD.

Features

  • A color correction filter is a filter that converts the sensitivity characteristics of a silicon detector with a peak in the near infrared into sensitivity characteristics similar to those of the human eye.
  • It is ***d as a filter to be attached to the CCD image sensor.
  • You can correct unnatural image colors ca***d by infrared rays by applying a filter.
  • The CCF5000 is highly weather-resistant, making it difficult for the glass surface to become misted even when ***d in an outdoor environment.
  • CCF-500C and CCF-5000 have different main components of glass.
  • The transmittance from visible to 900 nm remains the same, but the transmittance of wavelengths above 900 nm is different.
  • ECM-500 has a darker color than CCF-500C and CCF-5000, and can cut near-infrared light.
  • * Cannot be ***d for high-power laser or high-energy pulse laser in the absorption wavelength range.
  • * Anti-reflection coat is not applied on both sides.
  • * Reflected light from the front and back ca***s a transmittance loss of about 10%.
  • * CCF-500C and ECM-500 are less weather-resistant than CCF-5000.
  • * Exposure to a high temperature and humidity environment for a long time may ca*** the skin to burn.

Spec

  • Average transmittance (400 - 600nm): 84.2%
  • Transmittance (600nm): About 60%
  • Transmittance limit wavelength: 654nm
  • Long-wavelength side *** wavelength: 829nm
  • Long-wavelength side *** transmittance: <3.0%
  • Average transmittance (long-wavelength side *** to 1200nm): <5.0%
  • RoHS conform product
