63-4945-29 4.7kΩ 1206 Thick Film SMD Resistor ±1% 0.25W - CRCW12064K70FKEA CRCW12064K70FKEA
Product Description
Product Model: 63-4945-29Product Brand: Vishay Features […]
Contact Us
Product Details
Product Model: 63-4945-29
Product Brand: Vishay
Features
- 1206 CRCW Series Surface Mount Fixed Resistor - 1% (Paper T/R) (ZeroΩ to 9.09kΩ). From Vishay, the CRCW series consists of surface mount thick film resistors. These SMD resistors are constructed from a high quality ceramic with a metal glaze. With pure tin plated solder contacts, you can *** soldering processes that either contain lead or are lead-free. Features and benefits:. 1206 package size. Available with resistance values ranging from 0 Ω to 10 MΩ. Protective overglaze. Excellent stability (ΔR/R ≤ 1 % for 1000h at +70 °C). Wide operating temperature range of -55°C to +155°C. ±1% tolerance. Applications:. These SMD resistors are suited to a wide range of applications include telecommunication equipment, cameras and computers. With an AEC-Q200 qualification, these SMD resistors are also suitable for automotive applications.
Spec
- Quantity:1bag(50pieces)
- Resistance : 4.7kΩ
- Technology : Thick Film
- Package/Case : 1206 (3216M)
- Tolerance : ±1%
- Power Rating : 0.25W
- Temperature Coefficient : ±100ppm/°C
- Series : CRCW
- Minimum Operating Temperature : -55°C
- Maximum Operating Temperature : +155°C
- CODE No.:679-2184
