63-4942-69 390Ω 0402 Thick Film SMD Resistor ±1% 0.063W - CRCW0402390RFKED CRCW0402390RFKED
Product Description
Product Model: 63-4942-69Product Brand: Vishay Features […]
Contact Us
Product Details
Product Model: 63-4942-69
Product Brand: Vishay
Features
- 0402 CRCW Series Surface Mount Fixed Resistors - 1% (Paper T/R) (10Ω to 9.76kΩ). From Vishay, the CRCW series consists of surface mount thick film resistors. These SMD resistors are constructed from a high quality ceramic with a metal glaze. With pure tin plated solder contacts, you can *** soldering processes that either contain lead or are lead-free. Features and benefits:. 0402 package size. Available with resistance values ranging from 0 Ω to 10 MΩ. Protective overglaze. Excellent stability (ΔR/R ≤ 1 % for 1000h at +70 °C). Wide operating temperature range of -55°C to +155°C. ±1% tolerance. Applications:. These SMD resistors are suited to a wide range of applications include telecommunication equipment, cameras and computers. With an AEC-Q200 qualification, these SMD resistors are also suitable for automotive applications.
Spec
- Quantity:1bag(50pieces)
- Resistance : 390Ω
- Technology : Thick Film
- Package/Case : 0402 (1005M)
- Tolerance : ±1%
- Power Rating : 0.063W
- Temperature Coefficient : ±100ppm/°C
- Series : CRCW
- Minimum Operating Temperature : -55°C
- Maximum Operating Temperature : +155°C
- CODE No.:678-9223
