63-4941-77 Mean Well 350W Isolated DC-DC Converter Chassis Mount, Voltage in 36 → 72 V dc, Voltage out 48V dc SD-350C-48
Electronic/Electrical Parts and Controll Equipments

63-4941-77 Mean Well 350W Isolated DC-DC Converter Chassis Mount, Voltage in 36 → 72 V dc, Voltage out 48V dc SD-350C-48

model: 63-4941-77
brand: Mean Well

Product Description

Product Model: 63-4941-77Product Brand: Mean Well Featu […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-4941-77
Product Brand: Mean Well

Features

  • De-rating below 0 and above 40°C. MTBF to MIL-HDBK-217F (25°C). 2. SD- 350 Series Single Output Enclosed Regulated Isolated DC-DC Converter. High reliability Wide 2:1 input voltage range Regulated outputs Easy installation - screw terminals Adjustable output voltage EMC meets EN 55022 Class B LED power-on indicator Short circuit, overload and overvoltage protection 1.5kV input / output isolation

Spec

  • Quantity:1piece
  • Output Voltage : 48V dc
  • Output Voltage Adjustment Range : 43 → 53V
  • Input Voltage Range : 36 → 72 V dc
  • Input Voltage Nominal : 96 V dc
  • Isolation Voltage : 1.5kV ac
  • Power Rating : 350W
  • Output Current : 7.3A
  • Mounting Type : Chassis Mount
  • Number of Outputs : 1
  • Efficiency : 82%
  • Minimum Temperature : -20°C
  • Maximum Temperature : +60°C
  • Depth : 50mm
  • CODE No.:678-3647
