63-4941-71 Mean Well 15W Isolated DC-DC Converter Chassis Mount, Voltage in 18 → 36 V dc, Voltage out 24V dc SD-15B24
Product Description
Product Model: 63-4941-71Product Brand: Mean Well Featu […]
Contact Us
Product Details
Product Model: 63-4941-71
Product Brand: Mean Well
Features
- De-rating below 0 and above 40°C. 2. SD-15 Series Single Output Enclosed Regulated Isolated DC-DC Converter. High reliability Wide 2:1 input voltage range Regulated outputs Easy installation - screw terminals Adjustable output voltages for the three types are; 24 V dc is 21- 26.4 V dc; 12 V dc is 10.8 - 13.2 V dc and 5 V dc is 4.75 - 5.5 V dc EMC meets EN 55022 Class B LED power-on indicator Short circuit, overload and overvoltage protection 2kV input / output isolation
Spec
- Quantity：1piece
- Output Voltage : 24V dc
- Output Voltage Adjustment Range : 21.6 → 26.4V
- Input Voltage Range : 18 → 36 V dc
- Input Voltage Nominal : 24 V dc
- Isolation Voltage : 2kV ac
- Power Rating : 15W
- Output Current : 625mA
- Mounting Type : Chassis Mount
- Number of Outputs : 1
- Load Regulation : ±0.2%
- Maximum Temperature : +60°C
- Depth : 28mm
- CODE No.:678-3559
