63-3103-13 LED (5 mm/green/high brightness/3.2 V/20 mA/6500 mcd) L5-G0030-6500
Product Description
Product Model: 63-3103-13Product Brand: Linkman Feature […]
Contact Us
Product Details
Product Model: 63-3103-13
Product Brand: Linkman
Features
- Pure green LED. Directivity is 30° for display. " InGaN (indium-gallium-nitrogen) is ***d instead of GaP (gallium-phosphorus), a conventional semiconductor material for green LEDs called "yellow-green." Beca*** the material is the same as the blue LED, the VF is as high as the blue LED and does not light at the same voltage as the conventional green LED.
Spec
- Colour of light emitted: green
- Body color: transparent
- Standard voltage (typ): 3.2 V
- Brightness (typ): 6500 mcd
- Directional: 30 degrees
- Peak wavelength (typ): 502 nm
- Condition IF: 20 mA
- Operating temperature: -20 to + 70 degrees C
- Storage temperature: -40 to + 85 degrees C
- Note: Actual products may vary slightly in voltage and brightness.
