63-4931-82 Epson 30MHz Crystal ±50ppm SMD 4-Pin 3.2 x 2.5 x 0.7mm Q22FA2380019311
model:
63-4931-82
brand:
SEIKO EPSON CORPORATION
Product Description
Product Model: 63-4931-82Product Brand: SEIKO EPSON COR […]
Contact Us
Product Details
Product Model: 63-4931-82
Product Brand: SEIKO EPSON CORPORATION
Features
- EPSON FA-238 Miniature SMD Crystal. FA-238 Series is a low profile surface mount crystal with a frequency range from 16 MHz to 60 MHz. Features ; Benefits:. Frequency range: 16 MHz to 60 MHz External dimensions: 3.2 x 2.5 x 0.7 mm Overtone order: Fundamental Applications: Mobile phone, Bluetooth, W-LAN ISM band radio, Clock for MPU
Spec
- Quantity：1bag(5pieces)
- Standard Frequency : 30MHz
- Mounting Type : Surface Mount
- Load Capacitance : 12pF
- Package Type : SMD
- Pin Count : 4
- Length : 3.2mm
- Width : 2.5mm
- Height : 0.7mm
- Dimensions : 3.2 x 2.5 x 0.7mm
- Frequency Tolerance : ±50ppm
- Frequency Stability : ±30ppm
- Series Resistance : 40Ω
- Minimum Operating Temperature : -40 °C
- Maximum Operating Temperature : +85 °C
- CODE No.:667-6202
