3-5958-01 Dry Cell Battery Driven Type Mass Flow Meter GCM-A-100mL, N2 GCM-A-100ml/N2
model:
3-5958-01
category:
toner
Product Description
Product Model: 3-5958-01 Features No electric wiring is […]
Contact Us
Product Details
Product Model: 3-5958-01
Features
- No electric wiring is required beca*** unit is driven by battery.
- Field operations can be performed via. integrated touch panel.
- Instantaneous flow rates and integrated flow amounts can be displayed concurrently or alternately.
Spec
- Model number: GCM-A-100ml, N2
- Full scale flow rate: 100ml
- Fitting port diameter: G1/4
- Accuracy: ±2%F.S..
- Measurement control range: 5 - 100% F.S..
- Response accuracy: 500msec
- Protection grade: IP50 compliance
- Power supply: AA dry cell x 1 piece (for test included), micro-USB power supply (5VDC 500mA)
