63-4919-36 Mean Well 156.5W Dual Output Embedded Switch Mode Power Supply SMPS, 2.7 A, 200 mA, 53.5/54V dc Enclosed AD-155C
Electronic/Electrical Parts and Controll Equipments

63-4919-36 Mean Well 156.5W Dual Output Embedded Switch Mode Power Supply SMPS, 2.7 A, 200 mA, 53.5/54V dc Enclosed AD-155C

model: 63-4919-36
brand: Mean Well

Product Description

Product Model: 63-4919-36Product Brand: Mean Well Featu […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-4919-36
Product Brand: Mean Well

Features

  • EN 60950-1, UL60950-1. UL, TUV. MTBF to MIL-HDBK-217F. 2. AD-55 and AD-155 Series Battery Backed PSUs. These 51 to 156 watt battery backed PSUs operate as an integrated power supply and battery charger capable of simultaneously powering an electrical device while charging a rechargeable battery.If the mains power supply fails, the unit will switch to the external battery, which will continue to power the electrical device until mains power is resupplied, or the battery runs out.They are designed to be ***d with batteries with a capacity below 3Ah. Universal AC input Battery charger UPS function Short circuit, overload ; over voltage protection Battery low protection Built in EMI filter 100% full load burn-in test Suitable for security industry or battery backup systems

Spec

  • Quantity:1piece
  • Output Voltage : 53.5/54V dc
  • Output Current : 2.7 A, 200 mA
  • Power Rating : 156.5W
  • Number of Outputs : 2
  • Input Voltage : 124 → 370 V dc, 88 → 264 V ac
  • Mounting Type : Chassis Mount
  • Package Type : Enclosed
  • Length : 199mm
  • Width : 110mm
  • Depth : 50mm
  • Weight : 880g
  • Efficiency : 84%
  • Maximum Temperature : +60°C
  • Minimum Temperature : -10°C
  • CODE No.:660-0151
