63-4913-46 Mean Well 600.7W 1 Output Embedded Switch Mode Power Supply SMPS, 44.5A, 13.5V dc Enclosed PSP-600-13.5
Product Description
Product Model: 63-4913-46Product Brand: Mean Well Featu […]
Contact Us
Product Details
Product Model: 63-4913-46
Product Brand: Mean Well
Features
- EN 60950, UL 60950. UL recognised, TUV, CB. Derate output 2% per °C above 50°C and below 0°C (no derating below 0°C to -20°C for SP750 Series). Depth excludes terminal blocks. 3. 500W to 700W, Universal Input, Single Output. High efficiency, long life and high reliability Built-in fan with speed control Remote sense Remote ON-OFF control Current sharing up to 2400W (3+1) (PSP-600 series only) LED indicator for power on Easy installation - screw terminals Adjustable output voltage (±10%) Power factor correction to EN 61000-3-2 EMC meets EN 55022 Class B Short circuit, over-load, over-voltage and over-temperature protection
Spec
- Quantity：1piece
- Output Voltage : 13.5V dc
- Output Current : 44.5A
- Power Rating : 600.7W
- Number of Outputs : 1
- Input Voltage : 124 → 370 V dc, 88 → 264 V ac
- Mounting Type : Chassis Mount
- Package Type : Enclosed
- Length : 170mm
- Width : 120mm
- Depth : 93mm
- Weight : 1.9kg
- Efficiency : 85%
- Maximum Temperature : +60°C
- Minimum Temperature : -20°C
- CODE No.:644-8240
