63-4902-53 Thick Film Chip Resistor 1005 Size RK73H1ETTP5601F
Product Description
Product Model: 63-4902-53Product Brand: KOA Features Th […]
Contact Us
Product Details
Product Model: 63-4902-53
Product Brand: KOA
Features
- Thick Film Chip Resistor, RK73H Series (Size 1005, 1%) Standard Reel
Spec
- Quantity: 1 bag (100 pieces)
- Resistance: 5.6 kΩ
- Technology: Thick Film
- Package/Case: 0402
- Tolerance: ± 1%
- Rating Power: 0.1 W
- Temperature Coefficient: ± 100 ppm/deg.
- Dimensions : 1 x 0.5 x 0.35 mm
- Height: 0.35 mm
- Operating temperature Min: -55 °C
- Operating temperature mAx: + 155 °C
- Maximum temperature coefficient: + 100 ppm/deg.
- RoHS Compliance Status: Compliance
- Securities Code: 631 -8278
