63-4895-59 Microchip PIC12F615-I/SN, 8bit PIC Microcontroller, 20MHz, 1K Flash, 8-Pin SOIC PIC12F615-I/SN
Product Description
Product Model: 63-4895-59Product Brand: Microchip Featu […]
Contact Us
Product Details
Product Model: 63-4895-59
Product Brand: Microchip
Features
- PIC12F609/615/617 8-Bit Flash Microcontrollers. Microchip s PIC12 Microcontrollers (MCUs) were the world s first 8-Pin microcontrollers. Originally launched as One Time Programmable (OTP) parts, this range of devices continues to expand as extra features and further improvements are added. The PIC12F609/615/617 family of microcontrollers is based upon Microchip s mid-range core with an 8 level deep hardware stack and 35 instructions. These MCUs provide up to 5 MIPS, up to 3.5 Kbytes program memory with data memory up to 128 bytes RAM. On board is a configurable RC oscillator with ±1% accuracy. Features. 35 Instructions 8 Level Hardware Stack 8 MHz Internal Oscillator – Selectable 4 MHz or 8 MHz 5 I/O Pins 1 Comparator 4 Channel 10-bit Analogue to Digital Converter (ADC) – PIC12F615/F617 only One 8-bit Timer – PIC12F615/F617 Two 8-Bit Timers One 16-bit Timer In Circuit Serial Programming (ICSP)
Spec
- Quantity:1piece
- Family Name : PIC12F
- Package Type : SOIC
- Mounting Type : Surface Mount
- Pin Count : 8
- Device Core : PIC
- Data Bus Width : 8bit
- Program Memory Size : 1024 x 14 words
- Maximum Frequency : 20MHz
- RAM Size : 64 B
- USB Channels : 0
- Number of PWM Units : 1
- ADC Channels : 4
- Number of SPI Channels : 0
- Typical Operating Supply Voltage : 2 → 5.5 V
- ADC Resolution : 10bit
- CODE No.:623-0156
