63-4894-67 RS PRO Type J Thermocouple 1m Length, 6.35mm Diameter, 0°C → 200°C 621-2344
Electronic/Electrical Parts and Controll Equipments

63-4894-67 RS PRO Type J Thermocouple 1m Length, 6.35mm Diameter, 0°C → 200°C 621-2344

model: 63-4894-67
brand: RS PRO

Product Description

Product Model: 63-4894-67Product Brand: RS PRO Features […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-4894-67
Product Brand: RS PRO

Features

  • RS Pro IEC Type J and Type K Thermocouple with Self Adhesive Copper Patch. From RS Pro IEC 584 standard Type J and Type K thermocouple temperature sensors designed for taking surface temperature measurements. The thermocouple lead has a durable Teflon PFA insulation and an ungrounded welded hot junction for a reduction in electrical interference. The *** of the thermocouple lead is terminated with a 6.35 mm diameter self adhesive copper pad for attaching to a surface. How does a Thermocouple Work?. A thermocouple is a sensor ***d to measure temperature in a range of different processes and consists of two wire legs made from different metals joined together at their two ***s to form two junctions. The hot, or measuring junction is connected to the body whose temperature is going to be measured. The cold junction or reference junction is connected to a body of known temperature. When the measuring junction is placed on something hot a voltage or potential difference between this and the reference junction occurs. This voltage can then be converted into a temperature measurement using thermocouple reference tables. This process is also known as the Seebeck Effect. What is a Surface Thermocouple?. This thermocouple is designed for measuring the temperature on a surface. Most thermocouples have a sensing tip where there ***s of the thermocouple wires are encased in sheaths or protection tubes which do not allow for measuring the temperature of a surface area. Surface temperature sensing thermocouples overcome this problem by having the sensing tip ho***d in a magnet or adhesive patch. The patch or magnet is then securely attached to the surface to be measured to provide a true surface contact. This affixing method allows these thermocouples to be ***d on many types of surfaces including uneven and circular surfaces. They are also simple to *** and easy to replace and position. Features and Benefits. Conforms to IEC 584 standards Ungrounded hot junction for reduction in electrical intereference Self adhesive copper patch for accurate surface sensing Durable Teflon PFA insulated leads for resistance to oils, acid, fluids and good mechanical strength and flexibility. Applications. Both these surface mount thermocouple are ideal for *** for permanent or temporary measurement in a range of applications including HVAC, air conditioning, plumbing and temperature mapping

Spec

  • Quantity:1piece
  • Thermocouple Type : J
  • Probe Diameter : 6.35mm
  • Probe Length : 1m
  • Maximum Temperature Sensed : +200°C
  • Termination Type : Cable
  • Cable Length : 1m
  • Standards Met : RoHS Compliant
  • CODE No.:621-2344
