63-4893-31 Wurth WE-PD Series Shielded Wire-wound SMD Inductor with a Ferrite Core, 470 μH ±20% 1.4A Idc 7447709471
Electronic/Electrical Parts and Controll Equipments

63-4893-31 Wurth WE-PD Series Shielded Wire-wound SMD Inductor with a Ferrite Core, 470 μH ±20% 1.4A Idc 7447709471

model: 63-4893-31
brand: Wurth Elektronik

Product Description

Product Model: 63-4893-31Product Brand: Wurth Elektroni […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-4893-31
Product Brand: Wurth Elektronik

Features

  • SMD Power Inductors Type WE-PD (Metal Base 1260 - 1210). Magnetically shielded version which results in a low leakage field High storage capacity Low self-losses Highest possible current loading for SMD Inductors Operating temperature -40 to +125°C Recomm***ed solder profile: Reflow Applications: Switching regulators with low operating voltages, Integrated DC/DC-converter, Perfectly suitable for switching regulators with extremely high efficiency (>86%), Graphic cards

Spec

  • Quantity:1piece
  • Inductance : 470 μH
  • Maximum DC Current : 1.4A
  • Length : 12mm
  • Depth : 12mm
  • Height : 10mm
  • Dimensions : 12 x 12 x 10mm
  • Shielded : Yes
  • Tolerance : ±20%
  • Maximum DC Resistance : 560mΩ
  • Series : WE-PD
  • Core Material : Ferrite
  • Maximum Self Resonant Frequency : 2MHz
  • Minimum Operating Temperature : -40°C
  • CODE No.:617-1669
