64-5698-32 ［Discontinued］5 W Digital 30ch (351 MHz) Handy Transceiver DJDPS50
Product Description
Product Model: 64-5698-32Product Brand: ALINCO INCORPOR […]
Contact Us
Product Details
Product Model: 64-5698-32
Product Brand: ALINCO INCORPORATED
Features
- You can also call other companies' digital transceivers!
- A registered station transceiver with a UHF 351 MHz land-based digital 30 channel power of 5 W. It can be switched to 2W for better balance of battery consumption and coverage area, or to 1W for longer operation.
- The EBP-82 DP-S50, which comes with a standard battery, is for light ***rs.
- IP67 equivalent immersion resistant body and screw-on waterproof accessory port protect the radio from dust, rain and snow. The body is made of durable polycarbonate for increased rigidity.
- It has a callback function that you can monitor your voice during transmission by using earphones.
- The PTT beep function has been adopted to prevent cutting off the head during a call.
- The liquid crystal display, which displays the settings of the radio equipment in an easy-to-understand manner, is a large dot matrix type with a backlight that is easy to see even at night. Of course, the display supports Kanji in Japanese.
- Calls can be made with up to 10 groups/up to 999 people at the same time, and 3 types of individual call functions.
Spec
- Frequency range: 351.2000 MHz to 351.38125 MHz (30ch: land only. You cannot *** it in the air or in the sea.)
- Modulation type 4-value FSK (Radio type F1E)
- Communication Method Single Communication (Press Talk)
- Transmit Output 5W/2W/1W Switchable Type (Deviation +20%, within -50%/Antenna Impedance: 50 Ω)
- Receive Sensitivity (12dB SINAD)? 8dBμ or less (BER 1x10 minus square)
- reception system double super heterodyne
- Low frequency output 700 mW or more (maximum)
- Rated voltage 7.4 V
- Current Consumption 1.7 A or Less (5 W Transmission) 1.1 A or Less (2 W Transmission) 0.9 A or Less (1 W Transmission)/500 mA or Less (Rated Receive) 85 mA or Less (Standby) 50 mA or Less (BS On)
- Operating Temperature Range: -10°C to +60°C (Charging Temperature Range: 0°C to +40°C)
- Rated Dimensions and Weight 56.9 x 98.5 x 43.5 mm (with Standard Battery Pack EBP -82) (Dimensions: Excluding Protrusions/Weight: With Antenna, Excluding Belt Clip/Strap)
- External Protection Grade Equivalent to IP67
- [Common Standard Accessories] Main Unit/Warranty, Owner's Manual, Application Documents/Hand Strap/Single Charging Stand EDC-196R/AC Adapter for Charging EDC-283/Antenna EA-198/Belt Clip EBC-27 [DJ-DPS 50] Li-ion Battery Pack EBP-82 (7.4 V 1500mAh) Before using the radio, apply for registration of the radio station to the competent regional communications bureau and obtain a registration certificate.
- Adopts AMBE codec and can make basic calls with other companies' digital communication (DCR registered station 3R) transceivers. *Note: It is not possible to communicate with the digital registration station of RALCWI system adopted by ALINCO.
