63-4880-50 Semi-Fixed Resistor 5 kΩ 0.125 W 1 Bag (5 Pieces) SM-3W5kOhm
model:
63-4880-50
brand:
Copal Electronics
Product Description
Product Model: 63-4880-50Product Brand: Copal Electroni […]
Contact Us
Product Details
Product Model: 63-4880-50
Product Brand: Copal Electronics
Features
- Cermet Trimmer SM-3 Series (11 turn model)
- 3mm size multiple turn trimmer (11 turn) Minute adjustments are possible SMT package suitable for reflow soldering Waterproof design Lead and cadmium free construction
Spec
- Number of Pieces: 1 Bag (5 Pieces)
- Maximum resistance: 5 kΩ
- Mounting type: surface mount
- Speed: 11
- bearing: top adjustment
- Rated power: 0.125 W
- Series: SM-3
- *** styles: J-Hook
- Tolerance: +/- 20%
- Temperature coefficient: +/- 100ppm/deg. C
- Shaft Diameter: 1.3 mm
- Operating temperature Min: -65°C
- Operating temperature mAx: +150°C
- RoHS Compliance Status: Compliance
- Securities Code: 602-4535
