Electronic/Electrical Parts and Controll Equipments
63-4880-08 DIP Switch Slide 4PST CES-0402MC
model:
63-4880-08
brand:
Copal Electronics
Product Description
Product Model: 63-4880-08Product Brand: Copal Electroni […]
Contact Us
Product Details
Product Model: 63-4880-08
Product Brand: Copal Electronics
Features
- Dip Switch CES Series
- Lead-free, cadmi-free Au-plated twin contacts for excellent contact stability Clear click feel
Spec
- Number of Pieces: 1
- Contact configuration: 4PST
- Contact current rating: 100 mA @ 6 V dc
- Contact Material: Copper Alloy, Gold Plated
- Number of positions: 4
- Mounting Type: PCB
- actuator types: sliding
- package styles: DIP
- Operating temperature mAx: +85°C
- Operating temperature Min: -40°C
- Operating temperature range: -40 → +85°C
- Insulation capacity: 500 V ac
- RoHS Compliance Status: Compliance
- Securities Code: 602-3425
