63-4877-60 E-TEC 2.54mm Pitch 18 Way,Through Hole Mount PCB Header, Tin Plated Contacts POS-318-S037-99
Product Description
Product Model: 63-4877-60Product Brand: E-TEC Features […]
Contact Us
Product Details
Product Model: 63-4877-60
Product Brand: E-TEC
Features
- Through Headers. Tin plated through headers, suitable for interconnecting two PCBs. They can be ***d with appropriate DIL socket to form a plug and socket pair, or can be directly soldered to the PCB. Inner contact material: Tin plated beryllium copper Outer pin material: Tin plated brass Current rating 3A 100 Cycles (Contact Life) Insulation Resistance: 5 x 10 ;sup>9 ;/sup>Ω (at 500Vdc) Operating Temperature -65°C to +175°C Flammability UL 94 V-0
Spec
- Quantity：1set(22pieces)
- Number of Contacts : 18
- Contact Plating : Tin
- Pitch : 2.54mm
- Termination Method : Solder
- Mounting Type : Through Hole
- Housing Material : PBT
- Width : 8.15mm
- CODE No.:600-7710
