Spec

• Validated products are Azuwan original services that conduct FAT (Factory Acceptance Test) at Azuwan before shipping.
• Validate (FAT) before shipping.
• After receiving the order, a FAT instruction form (plan) is sent to the ***r, and after the signature is returned, the FAT is performed.
• App***ix: FAT report/Calibration Certificate of ***d measuring instrument copied
• *I am attaching Azwan's original FAT instruction manual (see the sample at the bottom left of the Screen).
• Temperature point: 1 point of 37 degrees Celsius
• Temperature setting range: -10 to + 80 degrees C (when using an antifreeze solution below 10 degrees C in a water tank)
• Minimum temperature setting: 0.1 °Celsius steps
• Temperature control accuracy: +/- 0.1 ~ 0.5 degrees C (performance of the controller alone)
• Temperature control system: PID + DAC (differential approach control), auto-tuning system
• Heater capacity: SUS spiral sheath heater 1000 W
• Refrigerator: Sealed rotary compressor 150 W (Refrigerant R 134 a)
• Stirring system: Water jet type
• Safety devices: Overcurrent breaker, overheat protection sensor, empty heat protection
• Power supply: 100 VAC 50/60 Hz 12 A
• Power cord length: 2 m (3P type with conversion adapter)
• Weight: approximately 12 kg
• Body
• External dimensions (mm): 210 x 297 x 367
• *Water tanks are sold separately.
• Local validation services (IQ/OQ) are also available.　Please contact us.
• *The on-site validation service is a service that performs installation qualification (IQ) and operational performance qualification (OQ) at the installation site and submits an inspection form.
• *If you would like to request a local IQOQ, please contact us separately. We need your installation address for the estimate.
