63-4859-77 Vishay 100Ω 30W Fixed Resistor ±5% ±150ppm/°C LTO030F100R0JTE3
Product Description
Product Model: 63-4859-77Product Brand: Vishay Features […]
Contact Us
Product Details
Product Model: 63-4859-77
Product Brand: Vishay
Features
- LTO30 Series 30W Thick Film Power Resistors. LTO30 series 30W thick film power resistors with a compact TO-220 package and a 30W at 25°C case temperature heatsink mounted. These LTO30 series 30W power resistors have a direct ceramic mounting on heatsink, a broad resistance range of R010 to 550K and are non-inductive.. Thick film ceramic resistors 30 Watt at 25°C case temperature heatsink mounted Direct mounting ceramic on heatsink TO-220 package Isolated case Adjusted by sand trimming to reduce hot spots
Spec
- Quantity：1piece
- Resistance : 100Ω
- Power Rating : 30W
- Tolerance : ±5%
- Technology : Thick Film
- Series : LTO30
- Package/Case : TO-220
- Lead Pitch : 5.08mm
- CODE No.:532-8268
