63-4855-01 Nichicon 3.3μF 100V dc Bipolar Electrolytic Capacitor, Through Hole 6.3 (Dia.) x 11mm +105°C 6.3mm 2.5mm UEP2A3R3MED
Product Description
Product Model: 63-4855-01Product Brand: NICHICON Featur […]
Contact Us
Product Details
Product Model: 63-4855-01
Product Brand: NICHICON
Features
- Bipolar Aluminium Electrolytic Capacitor, EP Series, 105°C. Bipolar aluminium electrolytic capacitor Ideal for *** where polarity is not fixed or indeterminate, such as exchange transmitters, loudspeaker crossover networks and motor shifters Operating temperature range -55 to +105°C Capacitance tolerance: ±20% Leakage current: l = 0.01 CV or 3 μA (whichever is larger) max.
Spec
- Quantity：1bag(5pieces)
- Capacitance : 3.3µF
- Voltage : 100V dc
- Mounting Type : Through Hole
- Technology : Electrolytic
- Dimensions : 6.3 (Dia.) x 11mm
- Height : 11mm
- Minimum Operating Temperature : -55°C
- Diameter : 6.3mm
- Maximum Operating Temperature : +105°C
- Lead Pitch : 2.5mm
- Series : EP
- Ripple Current : 25mA
- CODE No.:523-2814
