63-4847-87 Nichicon 100μF 10V dc Aluminium Electrolytic Capacitor, Through Hole 6.3 (Dia.) x 11mm +105°C 6.3mm 2.5mm UPM1A101MED
Product Description
Product Model: 63-4847-87Product Brand: NICHICON Featur […]
Contact Us
Product Details
Product Model: 63-4847-87
Product Brand: NICHICON
Features
- Nichicon PM Series Electrolytic Capacitors. Nichicon PM Series Aluminium Electrolytic Capacitors are high reliability, low impedance products that have a 5000-hour load life and are compliant to the RoHS directive (2011/65/EU). The PM series features a wide temperature range, a rated voltage range of 6.3 V to 450 V, and high ripple current. Features ; Benefits:. High reliability High ripple current Long life up to 5000 hours Lead free reflow soldering Extremely low impedance
Spec
- Quantity：1bag(5pieces)
- Capacitance : 100µF
- Voltage : 10V dc
- Mounting Type : Through Hole
- Technology : Electrolytic
- Dimensions : 6.3 (Dia.) x 11mm
- Height : 11mm
- Minimum Operating Temperature : -55°C
- Diameter : 6.3mm
- Maximum Operating Temperature : +105°C
- Lifetime : 2000h
- Series : PM
- Tolerance : ±20%
- CODE No.:520-1393
