Electronic/Electrical Parts and Controll Equipments
63-4845-50 Nichicon 220μF 10V dc Aluminium Electrolytic Capacitor, Through Hole 6.3 (Dia.) x 11mm +105°C 6.3mm 2.5mm UPS1A221MED
Product Description
Product Model: 63-4845-50Product Brand: NICHICON Featur […]
Contact Us
Product Details
Product Model: 63-4845-50
Product Brand: NICHICON
Features
- Nichicon PS Series Capacitors. Nichicon PS Series Aluminium Electrolytic Capacitors are high reliability polymer capacitors which are rated up to 3000 hours. The PS series capacitors offer a high temperature range, high voltage, low impedance and high ripple current. Features ; Benefits:. High reliability High ripple current Long life up to 3000 hours Lead free reflow soldering Low ESR. Wide temperature range Miniature sized
Spec
- Quantity：1bag(5pieces)
- Capacitance : 220µF
- Voltage : 10V dc
- Mounting Type : Through Hole
- Technology : Electrolytic
- Dimensions : 6.3 (Dia.) x 11mm
- Height : 11mm
- Minimum Operating Temperature : -55°C
- Diameter : 6.3mm
- Maximum Operating Temperature : +105°C
- Lifetime : 2000h
- Series : PS
- Leakage Current : 4 μA
- CODE No.:519-3848
