63-4831-70 Recom ROM 1W Isolated DC-DC Converter Through Hole, Voltage in 4.5 → 5.5 V dc, Voltage out 5V dc ROM-0505S
Product Description
Product Model: 63-4831-70Product Brand: Recom Features […]
Contact Us
Product Details
Product Model: 63-4831-70
Product Brand: Recom
Features
- EN60950-1, EN60601-1. Operating temperature is without derating. Recom 1W SIP Single Output Unregulated Isolated DC-DC Converter - ROM Series. Micro size SIP4 package 3kVdc isolation UL 94V-0 package material Industry standard pinout Efficiency at full load up to 80%
Spec
- Quantity：1piece
- Output Voltage : 5V dc
- Input Voltage Range : 4.5 → 5.5 V dc
- Input Voltage Nominal : 5 V dc
- Isolation Voltage : 3000V dc
- Power Rating : 1W
- Output Current : 200mA
- Mounting Type : Through Hole
- Number of Outputs : 1
- Efficiency : 78%
- Package : SIP
- Load Regulation : ±15%
- Maximum Temperature : +85°C
- Depth : 7.7mm
- CODE No.:494-3838
