Spec

• Filtration area, cm

  ²

  : 200
• Filter bore diameter, μm: 0.45
• Processing capacity, L: 20
• Support material: Polycarbonate
• Device material: Polycarbonate
• Vent cap material: PVDF
• Material: Hydrophilic PVDF
• Filter brand name: Durapore(R)
• Brand name: Millipak
• Main application: Laboratory Filtration
• Package: Blister
• Form: Stacked disc
• Connection, Inlet/outlet: 19mm (3/4in.) sanitary flange
• Quantity/box: 2
• Overview: Millipak 40 filter unit 0.45μm 3/4in. TC/TC sterilized
• Product name: Millipak-40 filter unit
• Bubble point, 23 °C:


  179kPa (26psig), wetted in water and air
• Maximum input pressure, kPa (psi): 517 (75) @ 25


  °C
• Maximum differential pressure, kPa (psid): Normal direction - 414 (60) @ 25 ℃; 172 (25) @ 80 ℃; 34 (5) @ 123 ℃; reverse direction - 69 (10) @ 25 ℃
• Flow rate, L/min: 8.5 @245


  kPa ΔP
• Wettability: Hydrophilic
• Sterilization: Autoclave sterilization at 123℃ for 90 minutes for 3 times; in-line steam sterilization is unavailable
• Sterility: Sterilized
• Total extract: The extractables level was equal to or less than 1.5


  mg per sterilized device after a 200


  mL flush and 24


  hours in water at controlled room temperature.
• Potassium permanganate reduced substance: After flushing by following water, comply with USP Oxidizable Substances Test, ?200mL
• ※We ask for your kind understanding that lead time might change If it is out of stock in Japan.
