Electronic/Electrical Parts and Controll Equipments
63-4811-46 Nichicon 4700μF 10V dc Aluminium Electrolytic Capacitor, Through Hole 12.5 (Dia.) x 25mm +85°C 12.5mm 5mm UVK1A472MHD
Product Description
Product Model: 63-4811-46Product Brand: NICHICON Featur […]
Contact Us
Product Details
Product Model: 63-4811-46
Product Brand: NICHICON
Features
- Aluminium Electrolytic Capacitor, VK Series, 85°C. Small-Size Aluminium Electrolytic Capacitor 85°C 2000 hr (Rated) PET sleeve (no PVC) Lead-free plating on terminals Usable temperature range: -40 to +85°C, -25 to +85°C (rated voltage: 450 V) Capacitance tolerance: ±20%
Spec
- Quantity：1bag(5pieces)
- Capacitance : 4700µF
- Voltage : 10V dc
- Mounting Type : Through Hole
- Technology : Electrolytic
- Dimensions : 12.5 (Dia.) x 25mm
- Height : 25mm
- Minimum Operating Temperature : -40°C
- Diameter : 12.5mm
- Maximum Operating Temperature : +85°C
- Lifetime : 2000h
- Series : VK
- Leakage Current : 3 μA, 4 μA
- CODE No.:475-7716
