Spec

• Validated products are Azuwan original services that conduct FAT (Factory Acceptance Test) at Azuwan before shipping.
• Validate (FAT) before shipping.
• After receiving the order, a FAT instruction form (plan) is sent to the ***r, and after the signature is returned, the FAT is performed.
• App***ix: FAT report/Calibration Certificate of ***d measuring instrument copied
• *I am attaching Azwan's original FAT instruction manual (see the sample at the bottom left of the Screen).
• Temperature point: 1 point of 37 degrees Celsius
• External dimensions (mm): approx. 85 x 405 x 270
• Tank internal dimensions (mm): about 520 x 390 x 175
• Materials: Water Tank/SUS 304 (with insulation), Controller Unit Exterior/SUS 304, Water Tank Cover/Rigid PVC
• Temperature setting range: room temperature + 5 ~ 60 degrees C (MAX 70 degrees C)
• Temperature control accuracy: +/- 1 degrees C (performance of the controller alone)
• Temperature controller: PID control
• Tank Stirring: Jet Stirring
• Heater capacity: 1 kW
• Body weight: About 12 kg
• Power supply: 100 VAC 50/60 Hz 11 A
• Power cord length: 2 m (3P plug)
• Safety device: Excess temperature rise prevention, float type empty heating prevention, motor with temperature f***
• *If you would like to request a local IQOQ, please contact us separately. We need your installation address for the estimate.
