Spec

• Product Type: USB To Specific Interface Conversion Cable
• Specifications: [Common Specifications]
• Interface standard: Compliant with USB specifications Ver. 3.1 Gen1 (USB3.0) (Upward compatible with USB Ver. 2.0/1.1)
• Communication speed: 5Gbps/480Mbps/12Mbps/1.5Mbps (theoretical)
• Connectors: 1 male USB3.1 Gen1 (USB3.0) A connector; 2 female HDMI Type A (19PIN); 1 RJ45 port
• power: bus power
• Power consumption: approx. 800 mA (max.)
• Maximum number of connections: 6
• Operating temperature range: 10°C to 40°C
• Operating Humidity Range: 0% to 80%
• Size: W131.3xD58.3xH19.4mm
• Weight: about 130 g
• Cable Length: Approx. 9 cm
• Accessories: Driver CD, Owner's Manual, Warranty [Video Output Unit]
• Connector: 2 female HDMI Type A (19PIN)
• Supported resolutions: 3840x2160 (60/30Hz), 3440x1440 (60/30Hz), 2048x1152 (60 Hz), 2048x1080 (60 Hz), 1920x1200 (60 Hz), 1920x1080 (50/60Hz), 1680x1050 (60 Hz), 1600x1200 (60 Hz), 1600x900 (60 Hz), 1440x900 (60 Hz), 1400x1050 (60/75/85 Hz), 1368x768 (60 Hz), 1366x768 (60 Hz), 1360x768 (60 Hz), 1280x1024 (60/75Hz), 1280x960 (60/85Hz), 1280x800 (60 Hz), 1280x768 (60/75/85 Hz), 1280x720 (50/60Hz), 1024x768 (60/70/75/85Hz), 800x600 (56/60/72/75/85 Hz), 640x480 (60/67/72/75/85 Hz)
• Dual display output: Supported [LAN port section]
• Interface standards: IEEE802.3 (10BASE-T Ethernet), IEEE802.3u (100BASE-TX Fast Ethernet), IEEE802.3ab (1000BASE-T)
• Communication mode: Full duplex/Half duplex
• access methods: CSMA/CD
• Port configuration: RJ-45 port (1000BASE-T/100BASE-TX/10BASE-T) Auto-MDIX with AutoNegotiation
• Power supply voltage: 5 V * Communication speed 1000BASE-T is supported only when USB3.1 (3.0) is connected.
• Securities Code: SN10Q9L
