65-3536-04 ［Out of stock］Tape Type Temperature Sensor Model 505 w/ISO Document -50~400°C 6 sec E Type 505E-TS1-ASP
Product Description
Product Model: 65-3536-04Product Brand: ANRITSU METER C […]
Contact Us
Product Details
Product Model: 65-3536-04
Product Brand: ANRITSU METER CO., LTD.
Features
- Model 503/505 is more resilient than ST series. Model 540 is a tape-type temperature sensor with a disk-shaped tip that is easy to stick and a flexible tape.
- [Application] Surface temperature measurement of metals and non-metals, etc.
Spec
- Operating temperature range (°C): -50~400
- Tolerance at 100 deg. C (deg. C): ±2.5
- Response Time (sec): 6
- Thermocouple Type: E Type
- Code Type: Standard Code
- Cord length (m): 1
- Plug Shape: Standard Plug
- Calibration temperature point: 100°C
- Document content: Inspection report, calibration certificate, traceability system diagram
