65-3535-80 ［Out of stock］Pipe Inner Surface Type Temperature Sensor Model 344 w/ISO Document -50~400°C Straight E Type 344E-TC1-ASP
Product Description
Product Model: 65-3535-80Product Brand: ANRITSU METER C […]
Contact Us
Product Details
Product Model: 65-3535-80
Product Brand: ANRITSU METER CO., LTD.
Features
- Model 305/344 is a pipe inner surface type temperature sensor capable of measuring the inner surface of pipes with an inner diameter of 8 mm or more.
- [Application] Temperature measurement of pipe inner surface, etc.
Spec
- Material: Pipe Material/Stainless Steel (SUS304), Grip Material/Black Phenol Resin
- Operating temperature range (°C): -50~400
- Tolerance at 0~100 deg. C (deg. C): ±2.5
- Response Time (sec): 5
- Durability: Over thousands of cycles
- pipe shapes: straight
- Thermocouple Type: E Type
- Code Type: Standard Code
- Cord length (m): 1
- Plug Shape: Standard Plug
- Calibration Temperature Point: 100, 200, 400°C
- Document content: Inspection report, calibration certificate, traceability system diagram
