65-3533-54 ［Out of stock］Temperature Sensor for Micro Surface CS Series with ISO Document -50~600°C Pipe Shape: Type 3 Type E CS-73E-010-1-TC1-ASP
Product Description
Product Model: 65-3533-54Product Brand: ANRITSU METER C […]
Contact Us
Product Details
Product Model: 65-3533-54
Product Brand: ANRITSU METER CO., LTD.
Features
- The CS Series is a temperature sensor for micro surfaces with a small temperature measuring section.
- We can measure the surface temperature of any object, not just electronic substrates.
- [Application] Heat generation temperature control and temperature measurement of electronic components on board
Spec
- Material: Pipe Material/Stainless Steel (SUS304), Grip Material/Black Phenol Resin
- Operating temperature range (°C): -50~600
- Tolerance at 100 deg. C (deg. C): ±2.5
- Response Time (sec): 2
- Durability: 50,000 cycles or more
- Head Tip Shape (φmm): 6
- Pipe Shape: Type 3
- Type of thermocouple: Type E
- Pipe length (mm): 100
- With/without grip: Yes
- Cord length (m): 1
- Cord Outer Diameter (φmm): 4
- Coating Material: Silicon
- Heat-resistant Temperature (°C): 240
- Plug Shape: Standard Plug
- Calibration Temperature Point: 100, 300, 500°C
- Document content: Inspection report, calibration certificate, traceability system diagram
