65-2584-26 [Discontinued]Dust Control Waterproofing Type Medium Duty Balance GF-10202M
Product Description
Product Model: 65-2584-26Product Brand: A&D Feature […]
Contact Us
Product Details
Product Model: 65-2584-26
Product Brand: A&D
Features
- Dustproof and waterproof IP65 allows you to measure even in a dusty environment or a sample with water droplets without worry.
- The measuring dish and plate holder and the rear part of the body frame can be removed, so it is easy to clean and clean.
- It has a shock absorber mechanism on the back side of the measuring plate to reduce the impact on the sensor.
- ISD [Impact Shock Detection] when the production line is installed: When an impact is applied to the measuring plate, a four-step warning display and a buzzer are displayed.
- FRD [Flow Rate Display] for liquid metering such as pump flow rate: Calculates the change in load as "flow rate". High precision flow rate measurement is possible with a single thread take-up.
- ECL [Electronically Controlled Load] for checking the repeatability of the balance and the minimum measurement value: A & D's unique internal mechanism calculates the repeatability of the balance (only 90 seconds) without using external weights.
- 2ch output standard of RS-232C interface (D-Sub9P male)/USB interface (Mini B type).
- With statistical calculation function and specific gravity measurement function.
- It has a security function to restrict the ***r of the balance and the setting of the watch.
- With clock function and data memory function.
Spec
- Minimum display (g): 0.01
- plate size (mm): 270 x 210
- Weighing (kg): 10.2
- Width (mm): 300
- Depth (mm): 355
- Height (mm): 111
- Repeatability (standard deviation): 0.01 g
- Linearity: ± 0.03 g
- Power Supply: AC adaptor (included)
- Power Supply: AC adaptor (included)
- Sensor Method: Super Hybrid Sensor
- official approval: Not applicable
- Set Contents/Accessories: Instruction Manual, AC Adapter, USB Cable (1.8 m), Display Cover, Simple Windshield
- Mass: 8.3 kg
- Country of Origin: Japan
- Securities Code: 248 -5432
