Spec

• Measurement Method: Eddy Current Method
• Measurement object: Insulating coating on non-magnetic metal
• Measuring range: 0~1200 μm
• Accuracy: ±1 μm for less than 50 μm, ±2% for 50 μm to less than 1000 μm, ±3% for 1000 μm or more
• Resolution: < 100 μm: 0.1 μm, ≥ 100 μm: 1 μm
• Compliance standards: JIS K5600-1-7, JIS H8680-2, JIS H8501/ISO 2808, ISO 2360, ISO 2064, ISO 19840/BS 3900 C5/ASTM D 7091-5, ASTM E 376
• Number of data memories: Approx. 39,000 points
• Calibration curve memory: Application memory: 100 calibration curves stored
• Probe: One-Point Contact Constant Pressure (LHP-J)
• Display Method: Digital (Backlit LCD, Minimum Display Digit 0.1 μm)
• External Output: Computer (USB or RS-232C)
• Power Supply: 1.5 V Battery (AA Alkali) x 4
• Power consumption: 80 mW (backlight off)
• Battery life: 100 hours (Continuous *** when backlight is off)
• Operating Temperature Range: 0~40°C
• Additional functions: 16 functions
• Dimensions and mass: 75 (W) x 145 (D) x 31 (H) mm, 0.　34Kg
• Accessories: Standard Plate (10 μm/50 μm/100 μm/500 μm/1000 μm, approximate value, 1 sheet each), Standard Plate Case, Aluminum Fabric (NFE-373), Probe Adapter, Carrying Case, Battery 1.5 V (AA Alkali) x 4
• Options: Standard Plate (Thickness other than accessories), Measurement Stand LW-990, Personal Computer Cable, RS-232C-USB Cable, Data Management Software: "Data Logger LDL-03"
