Spec

• DC Voltage: [Range] 60 m/600 m/6/60/600/1000 V
• AC voltage (true effective value measurement): [Range] 60 m/600 m/6/60/600/750 V
• DC Current: [Range] 600 μm/6000 μm/60 m/600 m/6/10 A
• Alternating current (true effective value measurement): [Range] 600 μm/6000 μm/60 m/600 m/6/10 A
• Resistance: [Range] 600/6 k/60 k/600 k/6 M/60 MΩ,
• Frequency: [Range] 100/1 k/10 k/100 k/1 M/10 MHz
• Capacitor capacity: [Range] 40 n/400 n/4 μ/40 μ/400 μ/4000 μF
• Power Supply: 6F 22 type (006P type) 9 V battery 1 piece
• With General calibration certificate
• [Accuracy]
• DC voltage: ± (0.5% rdg + 1 dgt) (highest accuracy)
• AC Voltage (True Effective Value Measurements): ± (1.0% rdg + 3 dgts) (Maximum Accuracy)
• DC Current: ± (1.0% rdg + 3 dgts) (Maximum Accuracy)
• AC Current (True Effective Value Measurements): ± (1.2% rdg + 5 dgts) (Maximum Accuracy)
• Resistance: ± (1.0% rdg + 2 dgts) (highest accuracy)
• Frequency: ± (0.1% rdg + 4 dgts) (highest accuracy)
• Capacitor capacity: ± (3.0% rdg + 5 dgts) (Maximum Accuracy)
• External dimensions: 87 (W) x 180 (H) x 40 (D) mm (Excluding Protrusions)
• Certificates: with General calibration certificate
• *The name and address of the person who requested the certificate will be blank.
• *Delivery will take about 2 weeks because we will proofread it after the order is confirmed. (However, please note that there will be additional days during the New Year's holiday.)
• *As this is a build-to-order product, we cannot accept returns after shipment.
